Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification

Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification
Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification

Hình ảnh lớn :  Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification

Thông tin chi tiết sản phẩm:
Nguồn gốc: Botou Hebei China
Hàng hiệu: HC
Chứng nhận: ISO
Số mô hình: HC400
Thanh toán:
Số lượng đặt hàng tối thiểu: 1set
Giá bán: 13000-29000USD
chi tiết đóng gói: Main machine is nude,the computer control box is packed by carton box
Thời gian giao hàng: 30days
Điều khoản thanh toán: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Khả năng cung cấp: 20 sets/month

Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification

Sự miêu tả
Điểm nổi bật:

metal forming machines

,

cold roll forming equipment

Meta Roofing Ridge Cap Cold Roll Forming Machine With CE Certification

Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification 0Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification 1



 Cap Forming Machine



Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 400mm

3. Rollers: 15 rows

4. Dimensions: 8.1*1.35*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Ridge Cap Roll Forming Machine Main parameter

No.

   Main parameter of Ridge Cap Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

400mm

3

Rollers

15rows

4

Dimensions

8100*1350*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

4m/min

8

Diameter of the roller

Φ66 mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-press form-cutting





Application



This product is widely used in many kinds of industrial factory, civilian buildings, and Roof board for attached part product. It has advantage of pretty appearance, durable using and so on.

Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification 2Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification 3Civilian Buildings Ridge Cap Cold Roll Forming Machine With CE Certification 4



Competitive Advantage







1. CE certification

2. hydraulic motor drive

3. Exported to more than 70 countries

4. suitable for various kinds of steel plate

5. voltage according to customer request
