Horizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed

Chứng nhận
chất lượng tốt Máy cán khuôn lợp giảm giá
chất lượng tốt Máy cán khuôn lợp giảm giá
Máy dễ sử dụng. Sếp rất tốt.

—— Mr.Angolon đến từ Châu Âu

Đây là một nhà sản xuất tốt, một người giao tiếp tiếng Anh tốt, và tôi thích máy móc của bạn. Đó là chất lượng tốt, và đẹp!

—— Mr.Mark đến từ Châu Phi

Nhà cung cấp tốt đẹp! Tôi thích giao hàng nhanh chóng và chu kỳ sản xuất nhanh chóng của bạn, sẽ giữ liên lạc với các bạn.

—— Mr.Jack từ Mỹ

Tôi trò chuyện trực tuyến bây giờ

Horizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed

Trung Quốc Horizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed nhà cung cấp

Hình ảnh lớn :  Horizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed

Thông tin chi tiết sản phẩm:

Place of Origin: China
Hàng hiệu: HC
Chứng nhận: ISO CE
Model Number: HC12

Thanh toán:

Minimum Order Quantity: 1set
Giá bán: USD8000-15000
Packaging Details: 1.Main roll forming machine and un-coiler is nude packing (If you need, we can also packed it with water-proof plastic) 2. PLC control system and motor pump are packed with water proof paper,spare parts in carton box. 3.One set of machine needs a 40' con
Delivery Time: 30 work days
Payment Terms: D/A, Western Union, L/C, T/T
Supply Ability: 20 sets per month
Contact Now
Chi tiết sản phẩm
Material: PPGi GI capacity: 20m/min
machine weight: 4.5T rollers: 45# steel
Type: 0.15mm-0.4mm Galvanized Steel Automatic Roof Roll Forming Machine / Roof Sheet Roll Forming Machine Suitable Material: Q235 or equivalent

Horizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed



Corrugated roof sheet making roll forming machine for sale is the special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, decoiling, continuous rolling and cold-forming, automatically cut to the size and specification which is required, and output the finished panels. The equipment adopts PLC control, AC frequency and adjusting the speed technology, and it realizes the continuous automatically production, therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.



Technical Parameters

No Item Parameter Remark
1

Suitable



Material

Type color steel
Width(mm) 1200 According to customer's requirement
Thickness(mm) 0.4-0.7 According to customer's requirement
Yield Strength(Mpa) 230-300 According to customer's requirement
2 Forming Speed(m/min) 20 Not including cutting time
3 Roller Material No.45 steel with hard chromized
4 Cutting Model Hydraulic Cutting According to customer's requirement
5 Power source Type 440V/3PH/60HZ According to customer's requirement



Machine Components

No Name Quantity Remarks
1 Decoiler 1set Up to customer
2 Main machine Pre-cutting device 1set Up to customer
Feeding device 1set
Roll forming system 1set
Post cutting device 1set
Hydraulic system 1set
3 Electric control system 1set
4 Supporter/Automatic Stacker 1set Up to customer

Horizontal Corrugated Roll Forming Machine Roof Sheet Making High SpeedHorizontal Corrugated Roll Forming Machine Roof Sheet Making High SpeedHorizontal Corrugated Roll Forming Machine Roof Sheet Making High Speed

  1. Q:Are you a manufacturer?
  2. A:Yes absolutely. Welcome a lot for your visiting to us.
  3. Q:What’s the delivery time?

    A:Normaly will take 60days, for small lines will take 30 days.

  4. Q:Do you have after-sale support?

    A:Yes, we’re always here for giving you advice and support for technical details since we have senior technician.

  5. Q:Is there quality control when manufacturing the lines?

    A:Yes, we have a group of team who will be responsible for quality control from laying off the raw material, processing the rollers and the other parts, make treatment on the roller surface and shaft, assembling, testing and packaging.

  6. Q:What’s your strength comparing to the other supplier?

    A:We’ll supplying you the best quality and service. We’ll give you good advise beyond your requirements. The lines are easily for installation and with low mantenance requirements.

  7. Q:Can we be your agency abroad?

    A:Surely if you have business for roll forming lines and we will welcome a lot for cooperating together
