Thông tin chi tiết sản phẩm:
|type:||cold roll forming||usage:||villa roof|
|life time:||10 years|
Color Steel Glazed Tile Roll Forming Machine , Roof Wall Cladding Roll Former Machine
1. Condition: New, Type: Tile Forming Machine.
2. Tile Type: Steel, Use: Roof.
3. Place of Origin: Wuxi, Brand Name: LUOLE
1. Tile roof roll forming machine is the most popular machine to produce cold rolled metal glazed tile roof. It is one of the important machine in building construction area.
2. We are professional manufacturer of tile roof roll forming machine and have rich experiences.
The feature and advantage of our tile roof roll forming machine:
1. The whole line of tile roof roll forming machine include the decoiler for coils from 5ton to 10ton, guide feeding device, roll forming machine, hydraulic cutting and auto stacker or manual stacker for finished products.
2. This line can be automatic running by inputting the length and batches in the PLC system.
3. The strong H beam base is treated to avoid the vibration when working.
All the forming rollers are CNC lathe processed to guarantee the accuracy.
4. All the rollers are high grate steel polished and chrome coated to guarantee the life
5. The human computer interface operate system will save human source to operate the production line.
● Material thickness: 0.4-0.8mm
● Material width: depend on customer’s requirement
● Forming Station: 13-20 ( depend on profile drawing )
● Working Speed: 0-6m/min
● Transporting Type: Chain Transmission
● Type of Cutting: Hydraulic cutting
● Electrical Control: PLC Frequency Control System with touch screen
● PLC: PANASONIC
● Encoder: OMRON
● Transducer: PANASONIC
● Machine Weight: about 5 Ton
The Equipment list is as follows:
|Decoiler||1||Loading the coil material|
|Feeding guide device||1||Feeding and guide the material sheel|
|Main roll forming machine||1||Roll form the metal sheet|
|Hydraulic step stamping||1||Stamping the tile step|
|Hydraulic Cutting blade||1||Cutting the formed products|
|Hydraulic Station||1||Provide power for cutting|
|PLC control cabinet||1||Electrical control system|
|Output table||1||Load the finished products|
The working flow layout:
Decoiler–feeding guide–roll forming machine–Hydraulic step stamping–Hydraulic cutting–Output table
Some sample profiles:
Our products are widely used in various industrial factory, civilian building, warehouse and easy steel building manufacturing, and have features such as nice appearance and durable.
· Excellent quality
· Reasonable price
· One class after sales-service
· 1 Year Warranty from shipment
· More than 15 years manufacturing experience
