CE Two Profile Panel Double Layer Roll Forming Machine High Speed

CE Two Profile Panel Double Layer Roll Forming Machine High Speed
CE Two Profile Panel Double Layer Roll Forming Machine High Speed

Hình ảnh lớn :  CE Two Profile Panel Double Layer Roll Forming Machine High Speed

Thông tin chi tiết sản phẩm:
Place of Origin: Botou Hebei China
Hàng hiệu: HC
Chứng nhận: ISO/CE
Model Number: HC23-33
Thanh toán:
Minimum Order Quantity: 1set
Giá bán: 15000-39000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month

CE Two Profile Panel Double Layer Roll Forming Machine High Speed

Sự miêu tả
color: blue type: automatic
control system: PLC control cutting method: hydraulic cut
working speed: 8-10m/min per month: 30 sets
Điểm nổi bật:

metal roll forming machine

,

sheet metal roll forming machines

CE Two Profile Panel Double Layer Roll Forming Machine High Speed



Application:



Double Layer Roll Forming Machine can separate produce glazed roof and IBR roof in one line or similar two profiles.

The products are widely used in building the steel-structure large-scale warehouse, plants, supermarkets, shopping malls, trade markets, stadiums, holiday villages, sanatoriums, hotels, villas, residences, and different kinds of greenhouses.



Technical Parameters:



1) Main motor power: 5.5kw

2) Drive: Chain

3) Main shaft dia: ¢76mm material: 45# forge steel and quenched

4) Roller material: 45# forge steel and quench treatment hardness 58-62, chrome coated 0.05mm

5) Roll station: 13 groups for upper layer and 11 groups for lower layer

6) Raw material: 0.3-0.8mm

7) Width of raw material: 1220mm

8) Valid width after fromed: 1150mm&1000mm9) Working speed: 10m--15m/min(Exclude cutting time)

10) Length Tolerance: ±2mm

11) Weight of machine: about 8ton

12) Size of machine: About 10500×1800×1900mm L x W x H

13) Color of machine: depend on customer14) Coder: Omron

15) Control: PLC Panasonic, made in Japan. 380V 50HZ

16) Computer operating panel: touching screen

17) Cutting: Hydraulic cutting18) Auto cutting when reach the set length.

19) Hydraulic power: 3KW

20) Blade material: Cr12,quenched 58°-62°

21) Working pressure:16mpa

22) Cutting tolerance: +/- 1.5mm



Working flow:



Uncoiler—Feeding—roll forming--- hydraulic cut to length—output table

CE Two Profile Panel Double Layer Roll Forming Machine High Speed 0CE Two Profile Panel Double Layer Roll Forming Machine High Speed 1CE Two Profile Panel Double Layer Roll Forming Machine High Speed 2



Character of main structure





a) The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and most of the connecter is screw which make the machine flexible and stronger.

b) All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.

c) We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .

d) It is very easy to install the equipment and suitable for producing in the factory.

e) Low noise with high efficiency



Advantage:



available for two profiles roof panel shared one frame, save the cost.

1) Used to produce different roof panels and wall panels
2) Produced panels have such advantages as below:
a) Fine profile
b) Attractive color
c) Agile connecting
d) Slightly curved
3) dual-level roll forming machine
4) We can design and manufacture different type of it to hit your particular profiles
