High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min

High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min
High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min

Hình ảnh lớn :  High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min

Thông tin chi tiết sản phẩm:
Place of Origin: Botou Hebei China
Hàng hiệu: HC
Chứng nhận: ISO
Model Number: HC146/196
Thanh toán:
Minimum Order Quantity: 1set
Giá bán: 12000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month

High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min

Sự miêu tả
Type: Shutter door frame roll forming machine Usage: Door frame
Capacity: 10m/min Thickness: 1.5-2.5mm
Length: Any Power: 5.5+4KW
Automatic: Yes Life time: 20 Years above
Warranty: Whole life
Điểm nổi bật:

metal Roll Forming equipment

,

steel frame roll forming machine

High Precise Roll Forming Machinery Shutter Door Frame 17 Rows





To achieve maximum customer satisfaction, we are highly engaged in offering High Precise Shutter Door Frame Roll Forming Machine. Our highly skilled professional make the use of quality approved components & cutting edge methodology keeping in mind the set industry norms. The offered High Precise Shutter Door Frame Roll Forming Machine is available in various specifications as per the clients exact requirements at market leading prices. This High Precise Shutter Door Frame Roll Forming Machine is appreciated among our clients for its sturdy construction, robust structure, high performance, reliability and less maintenance.





Description:



High Precise Shutter Door Frame Roll Forming Machine Main parameter

No.

  High Precise Shutter Door Frame Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

260/310mm

3

Rollers

17 rows

4

Dimensions

8200*1350*1510mm

5

Power

5.5+4kw

6

Rolling material

shaft bearing steel(quenching)

6

Thickness of the plate

0.6-1mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ80mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control





Equipment components: Man-made uncoiler-leveling-roll forming machine-computer control system-hydraulic control system- cutting



Competitive Advantage



1. CE certification

2. ISO certification

3. working life 20 years

4. high quality steel

5. High efficiency



High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min 0High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min 1High Precise Roll Forming Machinery Shutter Door Frame 17 Rows 10m / min 2
