Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized

Khách hàng đánh giá
Máy dễ sử dụng. Sếp rất tốt.

—— Mr.Angolon đến từ Châu Âu

Đây là một nhà sản xuất tốt, một người giao tiếp tiếng Anh tốt, và tôi thích máy móc của bạn. Đó là chất lượng tốt, và đẹp!

—— Mr.Mark đến từ Châu Phi

Nhà cung cấp tốt đẹp! Tôi thích giao hàng nhanh chóng và chu kỳ sản xuất nhanh chóng của bạn, sẽ giữ liên lạc với các bạn.

—— Mr.Jack từ Mỹ

Tôi trò chuyện trực tuyến bây giờ

Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized

Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized
Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized
Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized

Hình ảnh lớn :  Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized

Thông tin chi tiết sản phẩm:
Place of Origin: CN
Hàng hiệu: HC
Chứng nhận: ISO CE
Model Number: HC25-185-740
Thanh toán:
Minimum Order Quantity: 1 set
Giá bán: USD10000-16000 per set
Packaging Details: Standard Export Package
Delivery Time: 40 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 set per month

Trapezoidal Profile Roof Tile Roll Forming Machine 380V Customized

Sự miêu tả
Type: Metal roofing sheet roll forming machine Suitable market: Asia
Usage: Roof and wall Power: 4+4KW
Voltage: 380V or customized Worker: 1 only
Forming speed: 10-20m/min Life time: 20 years above
Warranty: Whole life
Điểm nổi bật:

roof tile roll forming machine

,

roof panel roll forming machine

Trapezoidal Profile Roll Forming Machine



We are one of the leading organization occupied in providing Metal Roofing Sheet Roll Forming Machine, which are producing by using high grade material.we designed a lots kinds of Metal Roofing Sheet Roll Forming Machine. due to the high graded superiority and our client fulfillment,The product by Metal Roofing Sheet Roll Forming Machine has many benefit such as beautiful and colorful outside, light weigh, long life durability. It was widely used in every corn world wide. we can develop special Metal Roofing Sheet Roll Forming Machine as per customer requirement.



Quick Details Trapezoidal Profile Roll Forming Machine

1. Suitable to process: Color steel plate
2. Width of the plate: 914mm
3.  Rollers: 19 rows
4. Dimensions: 9*1.55*1.51m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12

10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Please note: All the parameters can be designed as customer's requirements.



Clear about working process for Roof Sheet Roll Forming Machine ?
Decoiling--Feeding & Guiding--Roll Forming--Cutting--Finished Products To Support Table

No.

   Main parameter of Roof Sheet Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

914mm

3

Rollers

19 rows

4

Dimensions

9100*1550*1510mm

5

Power

4+4kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Why choose Huachen ?


1. Q: Do you have after sales support?
A: Yes, we are happy to give advice on machine operating and maintenance. we also have skilled technicians available abroad to help you.We need your machines running in order to keep your business running.

2. Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly .We need to make gress to move forward.

3. Q: How does your factory do regarding quality control?
A: Quality is priority.To all Huachen people,the concept "Control every process and perfect all products" is curved in mind. Every product will be fully assembled and carefully tested before it's packed for shipment.

4. Q: Do you sell only standard machines?
A: No, most of our machines are designed according to customers specifications,we offer OEM service.

5. Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. welcome to come and check your machine after finished, or we will show you machine working video for confirm. Then delivery.
