Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe

Chứng nhận
chất lượng tốt Máy cán khuôn lợp giảm giá
chất lượng tốt Máy cán khuôn lợp giảm giá
Máy dễ sử dụng. Sếp rất tốt.

—— Mr.Angolon đến từ Châu Âu

Đây là một nhà sản xuất tốt, một người giao tiếp tiếng Anh tốt, và tôi thích máy móc của bạn. Đó là chất lượng tốt, và đẹp!

—— Mr.Mark đến từ Châu Phi

Nhà cung cấp tốt đẹp! Tôi thích giao hàng nhanh chóng và chu kỳ sản xuất nhanh chóng của bạn, sẽ giữ liên lạc với các bạn.

—— Mr.Jack từ Mỹ

Tôi trò chuyện trực tuyến bây giờ

Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe

Trung Quốc Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp
Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe nhà cung cấp

Hình ảnh lớn :  Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe

Thông tin chi tiết sản phẩm:

Place of Origin: Botou Hebei China
Hàng hiệu: HC
Chứng nhận: ISO
Model Number: HC312

Thanh toán:

Minimum Order Quantity: 1set
Giá bán: 13000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Contact Now
Chi tiết sản phẩm
Usage: Roof ridge Material: PPGI,GI
Capacity: 2-4m/min Weight: 2.8T
Size: 8.6*1.35*1.51m Warranty: Life time

Color Steel Glazed Ridge Cap Roll Forming Machine



Our firm is engaged in offering a wide array of Roof Ridge Cap Roll Forming Machine that is widely used in construction industry for making the roof tile outside of building. The components used for its fabrication are procured from reliable sources of the market to deliver high performance and superior quality at users end. Our offered Roof Ridge Cap Roll Forming Machine is highly appreciated for its outstanding functionality, sturdy construction, optimum strength, easy usage and longer functional life. We offer this machine in different specifications to fulfill the diverse needs of clients at most affordable prices.

Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe



Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 400mm

3. Rollers: 15 rows

4. Dimensions: 8.1*1.35*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:Metal Roof Profile Ridge Cap Roll Forming Machine Designed for Villadom

Main parameter

No.

   Main parameter of Ridge Cap Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

400mm

3

Rollers

15rows

4

Dimensions

8100*1350*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

4m/min

8

Diameter of the roller

Φ66 mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-press form-cutting

Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe

Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to EuropeColor Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to EuropeColor Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe

Application



This product is widely used in many kinds of industrial factory, civilian buildings, and Roof board for attached part product. It has advantage of pretty appearance, durable using and so on.

Color Steel Glazed Ridge Cap Roll Forming Machine with PLC Computer Control to Europe



Competitive Advantage



1. save space

2. easy install

3. perfect service

4. excellent quality

5. save freight

Why choose Huachen ?
1.Q: Do you have after sales support?
A: Yes, we are happy to give advice on machine operating and maintenance. we also have skilled technicians available abroad to help you.We need your machines running in order to keep your business running.

2.Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly .We need to make gress to move forward.

3.Q: How does your factory do regarding quality control?
A: Quality is priority.To all Huachen people,the concept "Control every process and perfect all products" is curved in mind. Every product will be fully assembled and carefully tested before it's packed for shipment.

4.Q: Do you sell only standard machines?
A: No, most of our machines are designed according to customers specifications,we offer OEM service.

5.Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. welcome to come and check your machine after finished, or we will show you machine working video for confirm. Then delivery.
