Thông tin chi tiết sản phẩm:
|
| Type: | cold roll forming | profile: | omega |
|---|---|---|---|
| Thickness: | 1mm | capacity: | 10m/min |
| weight: | 5T | warranty: | 1 year |
| Điểm nổi bật: | Plate roll forming machine,sheet metal forming equipment |
||
Colored steel are widely used in building: the steel-structured large scale warehouses, plants, super markets, shopping malls, trade markets, stadiums, holiday villages, sanatoriums, hotels, villas, residences, and different kinds of greenhouses. What's more, equipment can be designed and manufactured as customers' requests.
|
Material thickness
|
1.5-3mm
|
|
Material yield stress
|
230~550 Mpa
|
|
Max. forming speed
|
16m/min
|
|
Roller material
|
45# steel with chrome treatment
|
|
Roller driven type
|
Chain transmission
|
|
Controller & operation
|
PLC & touch screen and button
|
|
Hydraulic system pressure
|
12 Mpa
|
|
Hydraulic station motor power
|
4Kw
|
|
Main motor power
|
11Kw
|
|
Total power
|
15Kw
|
|
Total weight
|
About 6000 Kgs
|
Quick Detail:
1. Suitable to process: Color steel plate
2. Width of the plate:210mm
3. Rollers: 13 rows
4. Dimensions: 6.6*1.35*1.51m
5. Power: 5.5+4kw
6. Rolling material: shaft bearing steel(quenching)
7. Thickness of the plate:0.8-1.2mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12
10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Description:
Keel Roll Forming Machine Main parameter
|
No. |
Main parameter of Keel Roll Forming Machine |
|
|
1 |
Suitable to process |
Color steel plate |
|
2 |
Width of the plate |
210 mm |
|
3 |
Rollers |
13 rows |
|
4 |
Dimensions |
6600*1350*1510mm |
|
5 |
Power |
5.5+4kw |
|
6 |
Rolling material |
shaft bearing steel(quenching) |
|
7 |
Thickness of the plate |
0.8-1.2 mm |
|
8 |
Productivity |
20m/min |
|
9 |
Diameter of the roller |
Φ50mm |
|
10 |
Voltage |
380V 50Hz 3phases |
|
11 |
Material of the cutting plate |
Cr12 |
|
12 |
Hydraulic |
40# |
|
13 |
Processing precision |
Within 1.00mm |
|
14 |
Control system |
PLC control |
Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting
1.Our machines can uses galvanized steel sheet, colored armor plate or aluminum plate as the material plate.
2. Controlling by computer, PLC display, operation is easy, running is steady and reliable,endurable,maintenance-free
3. We can make and design with kinds of roll forming machine according to customer's request.
