New style double layer aluminium roof tiles roll forming machine

Chứng nhận
chất lượng tốt Máy cán khuôn lợp giảm giá
chất lượng tốt Máy cán khuôn lợp giảm giá
Máy dễ sử dụng. Sếp rất tốt.

—— Mr.Angolon đến từ Châu Âu

Đây là một nhà sản xuất tốt, một người giao tiếp tiếng Anh tốt, và tôi thích máy móc của bạn. Đó là chất lượng tốt, và đẹp!

—— Mr.Mark đến từ Châu Phi

Nhà cung cấp tốt đẹp! Tôi thích giao hàng nhanh chóng và chu kỳ sản xuất nhanh chóng của bạn, sẽ giữ liên lạc với các bạn.

—— Mr.Jack từ Mỹ

Tôi trò chuyện trực tuyến bây giờ

New style double layer aluminium roof tiles roll forming machine

Trung Quốc New style double layer aluminium roof tiles roll forming machine nhà cung cấp
New style double layer aluminium roof tiles roll forming machine nhà cung cấp New style double layer aluminium roof tiles roll forming machine nhà cung cấp New style double layer aluminium roof tiles roll forming machine nhà cung cấp New style double layer aluminium roof tiles roll forming machine nhà cung cấp New style double layer aluminium roof tiles roll forming machine nhà cung cấp

Hình ảnh lớn :  New style double layer aluminium roof tiles roll forming machine

Thông tin chi tiết sản phẩm:

Place of Origin: Botou Hebei China
Hàng hiệu: HC
Chứng nhận: ISO
Model Number: HC12/17

Thanh toán:

Minimum Order Quantity: 1set
Giá bán: 17000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Contact Now
Chi tiết sản phẩm
Material: PPGI GI Usage: roof and wall
capacity: 10m/min weight: 6T
length: 8m warranty: 1 year

New style double layer aluminium roof tiles roll forming machine



Equipment Description

1. Material:

1) Coil Width: 1000mm

2) Suitable Coil Thickness: 0.3-0.7mm

3) Suitable Raw Material: Galvanized steel sheet

2. The Chart of Process flow

New style double layer aluminium roof tiles roll forming machine

Manual de-coiler --- Electric Feeding --- Servo motor feeding ----oll Forming Machine------Computer Control Cabinet---Automatic cutting Mechanism ---Run-out Tables

3. The equipment including

Roll forming machine 1 set
Hydraulic cutter 1 set
Electrical control system 1 set
Hydraulic system 1 set
Normal run out table 3 PC 1m*1m
Manual de-coiler 1 set Max. loading 5 T

Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 1250mm

3. Rollers: 10/17 rows

4. Dimensions: 9.7*1.55*1.91m

5. Power: 4+4kw

6. Rolling material: high grade 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Double layer roll forming machine Main parameter

No.

 Main parameter of Double layer roll forming machine



1

Suitable to process

Color steel plate

2

Width of the plate

1250mm

3

Rollers

upper level :10 rows

Down level :17 rows

4

Dimensions

9200*1550*1910mm

5

Power

4+4kw

6

Rolling material

high grade 45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

20m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system- cutting



New style double layer aluminium roof tiles roll forming machineNew style double layer aluminium roof tiles roll forming machineNew style double layer aluminium roof tiles roll forming machineNew style double layer aluminium roof tiles roll forming machineNew style double layer aluminium roof tiles roll forming machine

Application



This kind of machine make two types of tile together perfectly, it has reasonable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the customer  with limit area or site





Payment terms and after-sale service:



1) FOB Tianjin



2) Payment: 30% T/T deposit, and pay the balance before shipping.



3) Delivery time: 30 working days.



4) Guarantee period: 12 months limited warranty starting from date of delivery. Shipping cost for parts to be replaced during warranty period have to be borne by the customer.



5) Spare parts: bearings, buttons, chains, magnetic valve, protective tube etc.



6) Installation and training:



1. If buyers visit our factory and check the machine, we will teach you how to install and us the machine, and also train your workers/technician face to face.



2. Without visiting, we will send you user manual and CD to teach you to install and operate.



3. COST OF INSTALLATION:



The buyer should pay the installation charges (USD 80 one man one day). To the seller’s appointed account by T/T before the seller’s technicians go to the buyer’s factory. The buyer pays the seller’s technicians travel cost outside China, including round air tickets fee, accommodation and food, provide transportation from living hotel to the work place, necessary communication, and insurance, etc.

If you have any further question of our Equipment, please feel free to contact me, thanks!
